5.9 C
IRCULATION
Settings required for ECO mode.
Only applies if a suction valve is configured (See 0
Suction valve).
E C O M o d e
This mode saves heating costs. The optimization of water circulation makes possible to
avoid heat losses and also to maximize the energy contributions under the cover.
This mode only apply for infinity pools wit cover configured.
OFF: ECO Mode is inactivate.
ON: ECO Mode is active: If air temperature is 1°C (fixed value) above Setpoint,
water circulation will go through buffer tank.
S e t p o in t
Applies when ECO Mode = ON
This is the air temperature used to trigger the circulation mode switchover (Buffer tank
or bottom drain).
B o t t o m c y c le
The user can decide to force circulation through the bottom drain during a period of
the day. Can be useful, for example, to reduce runoff noise at night.
If the conditions are met (no other circulation constraints) then flow will be
established through the bottom drain during the defined time slot.
S u r f a ce c y c l es
The user can decide to force circulation through the buffer tank (ie form the surface)
during up to four periods per day.
If the conditions are met (no other circulation constraints) then flow will be
established through the buffer tank during the defined time slots.
P a g e | 1 1 2
M
ODES
C I R C U L A T I O N M O D E s
> ECO Mode
Setpoint
Bottom Cycle
00:00 => 00:00
Surface Cycles
00:00 => 00:00
00:00 => 00:00
00:00 => 00:00
00:00 => 00:00
S E L E C T
Text:
Default:
Values:
Text:
Default:
Values:
Text:
Default :
Values :
Text:
Default :
Values :
: OFF
: 20.0°C
Q U I T
ECO Mode
OFF
OFF;
ON
Setpoint
20°C (68°F)
0°C - 50°C
(32°F - 122°F)
Bottom Cycle
ON=00 :00
OFF=00 :00
00 :00 ;
23 :59;
Surface Cycles
ON=00 :00
OFF=00 :00
00 :00 ;
23 :59;
