PoolCop Evolution Installer And User Manual page 46

P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
Relay
Function
Label
AUX AUX8
AUX AUX9
AUX AUX10
AUX AUX11
AUX AUX12
AUX AUX13
AUX AUX14
AUX AUX15
* See extras functionalities in 3.7.3
If you are unsure of the applicable wattage rating, contact the distributor of the auxiliary apparatus to
Inputs table:
Input
Function
Label
INPUT IN3-GND
INPUT IN4-GND
INPUT IN5-GND
INPUT IN6-GND
INPUT IN7-GND
INPUT IN8-GND
INPUT IN9-GND
INPUT IN10-GND
* See extras functionalities in 3.7.3
P a g e | 4 6
Relay
Connector
ID
K1 J2 6A/230V
6A/230V
K2 J2
6A/230V
K3 J2
6A/230V
K4 J2
6A/230V
K5 J1
6A/230V
K6 J1
6A/230V
K7 J1
K8 J1 6A/230V
Table 2 Relays and Power Ratings
Never exceed the power ratings.
Always conform to local installation norms and requirements.
Connector Examples of possible use
J11 Consumables Low, Pump Start, Pump Stop, Pool Cover, Etc.
J11 Consumables Low, Pump Start, Pump Stop, Pool Cover, Etc.
J11 Consumables Low, Pump Start, Pump Stop, Pool Cover, Etc.
J11 Consumables Low, Pump Start, Pump Stop, Pool Cover, Etc.
J12 Consumables Low, Pump Start, Pump Stop, Pool Cover, Etc.
J12 Consumables Low, Pump Start, Pump Stop, Pool Cover, Etc.
JetStream Control *
J12
Consumables Low, Pump Start, Pump Stop, Pool Cover, Etc.
J12 Consumables Low, Pump Start, Pump Stop, Pool Cover *, Etc.
Table 3 Inputs Table
Inputs are self-powered with low voltage.
Only use potential free signal without any external power supply.
Rating Examples of possible use
Pool Heating, Booster Pump, Garden Lighting, Irrigation, Etc.
Pool Heating, Booster Pump, Garden Lighting, Irrigation, Etc.
Pool Heating, Booster Pump, Garden Lighting, Irrigation, Etc.
Pool Heating, Booster Pump, Garden Lighting, Irrigation, Etc.
Pool Heating, Booster Pump, Garden Lighting, Irrigation, Etc.
JetStream *, Pool Heating, Booster Pump, Garden Lighting,
Irrigation, Etc.
Pool Cover OPEN Command *, Pool Heating, Booster Pump,
Garden Lighting, Irrigation, Etc.
Pool Cover CLOSE Command *, Pool Heating, Booster Pump,
Garden Lighting, Irrigation, Etc.
WARNING:
CAUTION:
confirm prior to connection.
CAUTION:
