P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
Electrolys 5 seconds
Protection
Overflow 2 sec
Open Cover 2 sec
Close Cover 2 sec
Electrolyser 2 sec
Protection
Aux Control 0 second
Note: the delay is used to filter out events of very short duration.

Analog Inputs

See FlowVis flowmeter installation guide.
P a g e | 1 0 4
When an electrolyser is controlled (ORP disinfectant = Salt or Ocean), or an aux label is set to
"Electrloyser" a specific flow switch can be installed to check flow in the electrolysis cell. No flow
will stop production with alert.
User can press a button to request pool to overflow at anytime. If no others functions prevent
overflow, then suction valve will be turned to overflow position. Only applies to infinity pool with
suction valve.
A key or button to request cover to open (if cover is configured). When key/button is release the
cover will stop in its position.
A key or button to request cover to close (if cover is configured). When key/button is release the
cover will stop in its position.
If a chlorinator is installed in bypass of the main circuit, production can be stopped by lack of
flow detected by a flow switch.
Uses to control an Aux status from an input. Aux control can be achieved in 4 different manners:
When Closed, Aux follows status of input, Aux timer deactivated.
When Open, Aux follows opposite status of input, Aux timer deactivated.
Pulse Close, Aux changes when input goes from OFF to ON, Aux timer possible.
Pulse Open, Aux changes when input goes from ON to OFF, Aux timer possible.
