Installing Options; Water Level Control - PoolCop Evolution Installer And User Manual

P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
3.7 I O
NSTALLING
Various equipment options are available. These serve to increase autonomy and enhance functionality.
W a t er L e ve l C o n tr o l
Valve kit is required. After installation, configure Water Level Control in the Configuration menu (see 5.4.1).
The water level will be replenished automatically when level is below setpoint provided that
when the setpoint is reached or the maximum adjustable refill duration is reached.
The water level will be reduced automatically when above setpoint
REDUCE or AUTO. With filter
cleaning is INHIBITED or MANUAL, the water may be sent to waste.
When filtration cycles are used (Filtration Modes TIMER, ECO+, VOLUME, CONTINUOUS, FORCE24, FORCE), water level is checked
and controlled only when filtration pump is stopped. To allow water level measurement, pump should be stopped at least 30
minutes between each filtration cycle. In these modes, when the pump starts, the refill valve closes automatically, unless the
continuous refill option has been selected.
When using 24/24 or NO_PUMP
periods. Water refill may start immediately but refill will be paused after 30 minutes. If the water level is not at setpoint at this moment,
refill will restart in the next 20 minutes. Several refill periods may be used to get to the setpoint. The maximum adjustable refill time
is still in place to protect against leaks.
Pool refill or water level reduction depend on configuration settings (see 5.4.1).
Pool Type Logic
Skimmer or Spa Refill occurs if level is not to the setpoint
when a level check is performed.
Refill stops as soon as setpoint is
reached. Level reduction can be done
with
Overflow Refills only occurs when water level is
LOW. Refill stops when level is
At the end of a filter cleaning, the water level is checked and readjusted (if refill is possible). To take overflow pools into account and
possible level fluctuations in the buffer tank, the refill action can be repeated up to 20 times, leaving a 20-second delay between each
level check. Repetitions stop as soon as the level stays at its set point.
When ready to commence the installation, the installer must:
Disconnect all electrical power to the pool and systems.
Close all valves, and if necessary, block all inlets to and outlets to/from the pool.
P a g e | 4 2
PTIONS
CLEANING: AUTO in Filter Data settings, cleaning cycles will be commanded to reduce the level. If
filtration modes, the level is checked and control every 20 minutes outside disinfection dosing
HIGH or V_HIGH level.
(HIGH or V_HIGH)
Refill
SetPoint= NORMAL
SetPoint = HIGH
When LOW
HIGH
MODE is set to REFILL
level is detected provided that
Level reduction
Selection HIGH
Selection V_HIGH
V_HIGH
When V_HIGH
or AUTO and stop
MODE is set to
