PoolCop Evolution Installer And User Manual page 102

P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
5.6.4.1.2 Sense of Action
The sensor action configures whether the alert action is taken when the circuit is closed (direct action) or open (reverse action).
For example:
If the thermostat contact closed indicates a freezing risk, choose "When Closed".
If the level detection senses that consumables are low by opening the contact in the switch, choose "When Open".
For Aux control it is also possible to deliver action on input state change:
Pulse Closed will toggle the Aux when the circuit goes from OFF to ON.
•
Pulse Open will toggle the Aux when circuit goes from OFF to ON.
•
Configures whether the alert is triggered when the circuit is closed (direct action) or
open (reverse action).
When configuring an input as a Flow Switch function, sense of action is preset to "When Closed"
5.6.4.1.3 Alert
Determines whether an Alert is associated with the sensing on the input or not.
If YES, when input is detected, an alert will be displayed on screen and send to server
(if connected to internet)
5.6.4.1.4 AuxID
When using an input role as "Aux Control", select which Auxiliary output to control.
To be controllable, an Aux must first have been configured at least with an identifier
(see 5.3.1 Auxiliary ID ). Input cannot control undefined Auxiliaries.
If using function as "Aux Control" and "When Closed" or "When Open" sense of action, the Aux output
P a g e | 1 0 2
When configuring an input as a Flow Switch function, Alert is preset to "NO"
will always and only be driven by the input, auxiliary timer will be voided.
NOTE:
and cannot be changed.
NOTE:
and cannot be changed.
NOTE:
Text: Action
Default: When Closed
Entries: When Closed;
When Open;
Pulse Closed;
Pulse Open
Text: Alert
Default: NO
Entries: NO;
YES
Text: Aux..
Default : None
Entries : Aux1;
.... ;
Aux15
