R e m n a n t I n j e ct i o n
Set Remnant parameters.
If possible, Remnant will be injected 1 hour before the end of the
latest filtration cycle of the day. If there is no filtration cycle long
enough, the longer cycle will be chosen, but the volume actually
injected may not fit the requirements.
When Filtration Mode is 24/24, injection will be set so that it ends at
10PM and re-calculated each day at midnight.
Installed
If INSTALLED: YES, PoolCop will control the Remnant injection according to
parameters settings.
If set to NO, this function is deactivated.
Aux Channel
Define the channel used to inject remnant.
Any available channels can be used.
Injection Rate
Set the feeder pump injection rate. Combined with pool volume
the injection rate will used to calculate the remnant injection duration.
Temperature
20°C (68°F)
26°C (79°F)
30°C (86°F)

Temperature Adjustment

Choose YES if the injected volume has to be corrected according to pool water
temperature.
If Yes, adjustment occurs between 24°C and 30°C (75.2°F and 86°F).
At 30°C (86°F), the injected volume is 2 times higher.

Extra Adjustment

Add an extra adjustment parameter applying a coefficient to the calculated volume as
follow:
LOW: Coefficient is 0.5 (half the volume, for example for indoor pools)
MEDIUM: Coefficient is 1.0
HIGH: Coefficient is 1.5 (1.5 times the volume, for high consumption pools)
Priming
Ensure the feeder pump is connected to chosen Aux and correctly powered.
Commanding priming ON
feeder pump to prime. Priming is stopped when quitting the menu or after 60 seconds.
Volume Injected
Per Day
6 ml/m 3
0.9 ml/m 3
12 ml/m
3
will activate the Aux channel for 60 seconds allowing the
P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
R E M N A N T I N J E C T I O N
> Installed
Aux Channel
Inj. Rate
Temp adjust
Extra adjust
Priming
S E L E C T
(POOL DATA menu),
Liquid Chlorine 12%
Increase of ppm
+0.72 ppm
+1.08 ppm
+1.44 ppm
: YES
: Aux2
: 1.5 l/h
: YES
: Med
: OFF
Q U I T
Text: Installed
Default: NO
Entries: YES,
NO
Text: Channel
Default: Any available channel
Entries: Aux1, etc.
Text: Inj. Rate
Default: 1.5 l/h
(9.5 GPD)
Entries: 0.1 to 9.9 l/h
(0.63 to 62.8 GPD)
Text: Temp. Adjst
Default: YES
Entries: YES, NO
Text: Extra Adjust
Default: Med
Entries: Low, Med, High
Text: Priming
Default: OFF
Entries: ON, OFF
