P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
7.4 CF1580-W1 K
No REF
10 BO1215.03
20 CHC-M6X70
30 CHC-M6X35
40 ETH-M6
50 W-6x14
60 PC1207
61 BO1215.21
62 BO1200.10
63 JT0001
64 W-32X43N
65 CF1210.16
66 JT0006
70 BO8015-W1
71 BO8015.04-W1
72 BO1200.06
73 JT0013
74 BO1200.04
75 JT0012
P a g e | 1 2 2
V 1.5" S80 W
IT ALVE
PART
Valve Spring 1.5''
Screw CHC M6x70mm
Screw CHC M6x35mm
Nut M6
Washer M6
Kit Diffuser 1.5''
Diffuser 1.5'' Gasket NBR
Cotter Pin 1.6mm
O-Ring VDU Base
Washer ID32mm Th 0.8mm Nylon
Positioning Disk Black
O-Ring Housing/Plug or shaft
Kit Valve Housing 1.5'' S80 White
Valve Housing 1.5'' S80 White
Sight Glass
Gasket Sight Glass
Drain Plug
O-Ring drain Plug
HITE
Qté
1
2
4
6
6
1
1
1
1
2
1
2
1
1
1
1
1
1
