P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
P u m p D a t a
Set pump parameters.
Pump Type
When entering the

PUMP DATA

pump from Single Speed Pump to a variable or variable speed pump, press the UP
arrow and press SELECT; now use the arrows to select the pump make and model
installed. See the PoolCop Variable Speed Pump Guide for further details including
connecting and programming.
Note: Binary combination offers the full possibilities of any combination using
Pump and Aux1/2/3 relays. This option can be used to control several mono
speed pumps.
SINGLE SPEED PUMP is selected for Pentair IntelliFlo pumps if connected without IntelliComm.
Low Alert
Set the pressure at which the Low Pressure Alert is activated.
This alert is used primarily to indicate that the skimmer or pump baskets are
contaminated, reducing flow and filter pressure.
This alert has no effect on the operation of equipment, it is an advisory only.
Setting the pressure limit:
Start the automatic pool cleaner and set valves.
Ensure that all debris has been removed from the baskets.
If using a variable speed pump, set minimum speed or flow programmed.
Let filtration run for a few minutes to expel any air in the system.
Note the low pressure reading on the PoolCop.
Round off to next lower round number and subtract a 0.20 bar (2.9 PSI)
margin.
Example
Lowest pressure noted = 0.76 bar (11 PSI)
Round DOWN = 0.70 bar (10 PSI)
Subtract 0.20 bar (2.9 PSI) = 0.50 bar (7.2 PSI)
If the alert "WARN: LOW PRESS" displays under normal circumstances, decrease this setting progressively.
P a g e | 9 6
menu, LOW ALERT is preselected. To change the
H A Y W A R D R a n g e V S T D
> Low Alert
Prot. Press
Prot. Pump
Def. Speed
Cyc 1 speed
Cyc 2 speed
Clean speed
S E L E C T
Text:
Default:
Entries:
NOTE:
Text:
Default:
Entries:
(min = PROT. PRESSURE see 5.6.2.3)
(max = FILTER PRESSURE see 5.6.3.1)
: 0.5 Bar
: 0.2 Bar
: YES
: 1
: 1
: 1
: 1
Q U I T
SINGLE SPEED PUMP
SINGLE SPEED PUMP
PENTAIR IntelliComm
PENTAIR SuperFlo VS
HAYWARD Eco Star
HAYWARD Range VSTD
BADU Eco Touch-pro
BADU 90 Eco Motion
ZODIAC FloPro VS
INVERTEK OptiDrive
Binary Combination
Davey ProMaster
VSD400
DAB E.SWIM_E.PRO;
AQUAGEM iSAVER+;
SACI epool ejoy;
SCHNEIDER ATV212
Low Alert
0.50 bar
(7.2 PSI)
0.1 to 2.40 bar
(1.45 to 34.8 PSI)
