P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
Removing the sensor from piping whilst there is pressure or a head of water in the circuit can cause water
Remove the blanking plug in the sensor housing.
Fit the sensor housing, with O-Ring.
Remove the liquid filled transport cap from the sensor.
The transport cap must be removed prior to fitting the sensor. Fitting the sensor without removing the
Check/adjust the grab ring, the grab ring must be between 25-30mm (0.98-1.18") from the sensor shoulder.
The blue (SO4902) or white (SO4903) band ensures spacing between the securing nut and the sensor shoulder.

Figure 45 - SO4902 Spacing, Grab Ring Adjustment

Check/adjust compression ring and O-Ring accordingly.
Fully insert the sensor into the housing, and secure with the nut.
Finger tighten the securing nut.
Ensure that the cap is sufficiently secure to retain the sensor in place under water pressure.
Remove the plastic cover from the PCB's.
Connect the sensor wire plug to JP6 onto the Connection SE Data PCB.
JP6 pH+ORP Sensor
Replace and secure the plastic cover.
Open valves and reconnect water supply, whilst checking for leaks.
P a g e | 3 6
transport cap will result in erroneous pH and ORP readings and chemical regulation.
Do not over-tighten as the electrode is a sensitive device.

Figure 47 - Connecting pH/ORP Sensor

CAUTION:
to flood and damage equipment.
CAUTION:

Figure 46 - SO4903 Spacing, Grab Ring Adjustment

CAUTION:
