PoolCop Evolution Installer And User Manual page 97

Protection Pressure
Set the pressure at which the pump protection will stop the pump to avoid damage
and activate an alert.
Setting the pressure limit:
Stop the pump and let indicated pressure stabilize.
Note the Pump OFF pressure reading on the PoolCop:
If the pump is higher than the pool, this should be 0 bar (0 PSI)
o
If the pump is lower than the pool, there should be a head of
o
pressure.
Round this figure up and add a margin of 0.20bar (2.9 PSI)
Set this pressure as the Prot. Pressure.
Example
Pump OFF pressure = 0.15 bar (2.2 PSI)
Round UP = 0.20 bar (2.3 PSI)
Add 0.20 bar (2.9 PSI) = 0.40 bar (5.8 PSI)
Activate Pump Protection
PoolCop protects the pump, by switching OFF the pump and integrated water
treatments in the event pressure measured is below the Prot. Pressure for 8 minutes. In
the case where pumps have their own protection systems, this protection can be
inhibited to prevent protection conflicts.
Switching Prot. Pump OFF disables the pump protection in the event that very low
pressure is measured. Alerts are still active, and in the event of the Alert activation other
internal functions (pH Control, ORP Control, Remnant injection) will stop.
Switching pump protection to OFF should only be done where the pump has its own protection system.
With Prot. Pump OFF, only integrated water treatment functions are stopped when this protection is
Def. Speed (if variable speed pump configured)
This will be the default speed when filtration is set in
If desired, 2 periods with different speed can be configured in
Cycle 1 Speed (if variable speed pump configured)
Select the speed linked to Filtration Timer cycle 1.
(Number of speeds depends on pump type)
Cycle 2 Speed (if variable speed pump configured)
Select the speed linked to Filtration Timer cycle 2.
(Number of speeds depends on pump type)
Cleaning Speed (if variable speed pump configured)
Select the speed linked to filter cleaning.
(Number of speeds depends on pump type)
P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
If in any doubt, Pump Protection should be ON.
activated; equipment connected to Aux relays will not be stopped.
24/24 MODE.
FILTRATION
Text:
Default:
Entries:
(max = LOW ALERT see 5.6.2.2)
Text:
Default:
Entries:
WARNING:
WARNING:
Text:
Default:
Menu.
Entries:
Text:
Default:
Entries:
Text:
Default:
Entries:
Text:
Default:
Entries:
Prot. Press.
0.20 bar
(2.9 PSI)
0.1 to 2.40 bar
(1.45 to 34.8 PSI
Prot. Pump
YES
YES, NO
Deflt Spd
1
1 to 8
Cyccle1 Spd
1
1 to 8
Cyccle2 Spd
1
1 to 8
CLean Spd
1
1 to 8
P a g e | 9 7
