Displaying IGMP Filtering and Throttling Configuration

Beginning in privileged EXEC mode, follow these steps to configure the throttling action when the
maximum number of entries is in the forwarding table:
Command
Step 1 configure terminal
Step 2 interface interface-id
Step 3 no shutdown
Step 4 ip igmp max-groups action {deny |
replace}
Step 5 end
Step 6 show running-config interface
interface-id
Step 7 copy running-config startup-config
To return to the default action of dropping the report, use the no ip igmp max-groups action interface
configuration command.
This example shows how to configure a port to remove a randomly selected multicast entry in the
forwarding table and to add an IGMP group to the forwarding table when the maximum number of
entries is in the table.
Switch(config)# interface gigabitethernet0/1
Switch(config-if)# ip igmp max-groups action replace
Switch(config-if)# end
Displaying IGMP Filtering and Throttling Configuration
You can display IGMP profile characteristics, and you can display the IGMP profile and maximum group
configuration for all interfaces on the switch or for a specified interface. You can also display the IGMP
throttling configuration for all interfaces on the switch or for a specified interface.
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
21-28
To prevent the switch from removing the forwarding-table entries, you can configure the IGMP
throttling action before an interface adds entries to the forwarding table.
Purpose
Enter global configuration mode.
Specify the physical interface to be configured, and enter interface
configuration mode. The interface can be a Layer 2 port that does not
belong to an EtherChannel group or an EtherChannel interface. The
interface cannot be a trunk port.
Enable the port, if necessary. By default, UNIs and ENIs are disabled,
and NNIs are enabled.
When an interface receives an IGMP report and the maximum number
of entries is in the forwarding table, specify the action that the interface
takes:
deny—Drop the report.
•
replace—Replace the existing group with the new group for which
•
the IGMP report was received.
Return to privileged EXEC mode.
Verify the configuration.
(Optional) Save your entries in the configuration file.
