Cisco ME 6500 Product Overview

Product Overview

This chapter describes the Cisco ME 6500 series Ethernet switches and contains these sections:
•
•
Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S)
The ME 6524 Ethernet switch (ME-C6524GS-8S) is a member of the Cisco ME 6500 series Ethernet
switches. The Cisco ME 6524 Ethernet switch (ME-C6524GS-8S) is a 1.5 RU horizontal chassis with
24 SFP downlink ports and 8 SFP uplink ports.
Ethernet switch (ME-C6524GS-8S) chassis.
Ethernet switch (ME-C6524GS-8S) chassis.
Figure 1-1
rear view of the chassis with the major features identified.
Table 1-1 Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S) Features
Feature
Chassis
Modules
Fan Tray
Power Supplies
OL-8900-01
Cisco ME 6524 Ethernet Switch (ME-C6524GS-8S), page 1-1
Cisco ME 6524 Ethernet Switch (ME-C6524GT-8S), page 1-8
shows the front view of the chassis with the major features identified;
Description
1.5 RU height, fixed configuration chassis
Fixed configuration chassis; modules cannot be installed in the chassis.
Supports one hot swappable fan tray (FAN-C6524). The fan tray
•
contains seven fans for chassis cooling. The individual fans are not
replaceable.
Fan tray FAN LED
•
Green—Fan tray is operating normally.
–
Red—One or more individual fans have failed.
–
Supports one or two power supplies. The following power supplies are
•
supported:
PWR-400W-DC (400 W DC-input power supply)
–
Power supply LEDs—Refer to
•
and their meanings.
C H A P T E R
Table 1-1 lists the features of the Cisco ME 6524
Table 1-2 lists the specifications of the Cisco ME 6524
Table 1-3 lists the front panel LEDs and their meanings.
Table A-1 on page A-1
Cisco ME 6500 Series Ethernet Switch Installation Guide
1
Figure 1-2 shows the
for LED colors
1-1
