10-2. Output State when Occurring an Error

Indicates the state of output signal when occurring an error.
Output
Item
"SE" LED is ON
Sensor disconnected error
"SE" LED is blinking
Sensor power supply error
"PF" LED is ON
Low power error
"ME" LED is ON
Memory error
"SWE" LED is ON
Switch setting error

10-3. Procedure Contents after Replacing

Implement the following measures after replacing the converter, ABSOCODER sensor, and sensor cable.
Replacing contents
In the case of replacing
ABOSOCODER sensor
In the case of replacing
the sensor cable
In the case of replacing
the converter
Position data output Latch pulse output
D0 to D25
Invalid
Invalid
Invalid
Invalid
Valid
Implements the following measures after the replacement.
1. Cancels an error either one of the following methods.
- Press CLR button.
- Input the error clear signal from external.
Refer to "8-7" for the procedure of error clear.
2. Sets the zero point either of the following methods after the
machine position is moved to the origin point.
- Press ZPS button.
- Input the zero point setting signal from external.
Refer to "8-6" for the procedure of zero position setting
Implements the following measures after the replacement.
1. Sets the zero point either of the following methods after the
machine position is moved to the origin point.
- Press ZPS button.
- Input the zero point setting signal from external.
Refer to "8-6" for the procedure of zero position setting
System ready output
LP NOR
Invalid
Invalid
Invalid OFF
Valid
OFF
Countermeasure
44
Error output
ERR
ON
