2. MODEL SELECTION WHEN ORDERING

Following figure is indicated connection configuration of "NCV-40H Series".
Before ordering, please refer to the connection configuration and model list.
Please prepare equipments by the customer except from ① to ④ in the connection configuration.
① Converter
Power
Supply
+24V
0V
Ground
Connector at cable side
(It is included in the converter.)
FCN-361J040-AU: Soldered socket
FCN-360C040-B: Cover
Connectors are manufactured
by FUJITSU COMPONENT LIMITED.
or
N361J040AU: Soldered socket
N360C040B: Cover
Connectors are manufactured
by OTAX CO.,LTD..
④ I/O Cable VS-C05-[L]
(Option)
③ Extension sensor cable
External output signal
-Position data
-Latch pulse
-System ready
-Error
② ABSOCODER sensor
Connector
type
B
P
R
2
PLC
External input signal
-HOLD
-Zero point setting
-Error clear
MRE-1024S16TS100
MRE-8192S2TS100
