3. SPECIFICATIONS

3-1. Converter Specifications

(1) General Specification
Items
Power supply voltage
Power consumption
Insulation resistance
Withstand voltage
Vibration resistance
Ambient operating temperature
Ambient operating humidity
Ambient operating environment
Ambient storage temperature
Grounding
Construction
Outside dimension (mm)
Mass
20 M-Ohms or more between external DC power terminals and ground
(by 500 VDC insulation resistance tester)
500 VAC, 60Hz for 1 minute between external DC power terminals and ground
20m/s 10 to 500Hz, 10cycles of 5 minutes in 3 directions,
2
20 to 90 %RH (No condensation)
Free from corrosive gases and excessive dust
Must be securely grounded (ground resistance of 100 ohm or less)
Book-shelf type within enclosure, DIN rail mountable
39(W) x 155(H) x 93(D) Refer to dimensions for details.
Specifications
24VDC±10% (including ripple)
10W or less
conforms to JIS C 0040 standard
0 to +55°C (No freezing)
-10 to +70°C
Approx. 0.4kg
