NSD Absocoder NCV-40H Series Specifications & Instruction Manual page 14

(3) Input / Output Specification
Items
Converter model
Input signals
Input circuit
Input logic
Input
Rated input voltage
Rated input current
ON voltage
OFF voltage
OFF→ON
Response
Time ON→OFF
Output signals
Output circuit
Output
Output logic
Rated load voltage
Max. load current
Max. voltage drop
when ON
*Refer to "6-3. Input / Output Connector Connection" about I/O circuit.
NCV-40H[ ]N[ ]
(Sink type)
HD (Position data HOLD): 1 point
ZPS (Zero point setting): 1 point
CLR (Error clear): 1 point
DC input, photo-coupler isolation
Negative logic
12 to 24VDC (10 to 30VDC)
10mA (24VDC)
10VDC or more
2VDC or less
0.1ms or less
0.1ms or less
D0 to D25 (Position data): 26 points
LP (Latch pulse): 1 point
NOR (System ready): 1 point
ERR (Error): 1 point
Photo-coupler isolation,
open drain (sink output)
Negative logic
12 to 24VDC (30VDC max.)
50mA / point
0.8V
6
Specifications
NCV-40H[ ]P[ ]
(Source type)
HD (Position data HOLD): 1 point
ZPS (Zero point setting): 1 point
CLR (Error clear): 1 point
DC input, photo-coupler isolation
Positive logic
12 to 24VDC (10 to 30VDC)
10mA (24VDC)
10VDC or more
2VDC or less
0.1ms or less
0.1ms or less
D0 to D25 (Position data): 26 points
LP (Latch pulse): 1 point
NOR (System ready): 1 point
ERR (Error): 1 point
Photo-coupler isolation,
open drain (source output)
Positive logic
12 to 24VDC (30VDC max.)
50mA / point
0.8V
