- Page 1 ZEF004479205 For Iron and Steel Industry ABSOCODER CONVERTER NCV-20HBNM2R NCV-20HGNM2R Specifications & Instruction Manual Applicable ABSOCODER: MRE-32SP061 MRE-G[ ]SP061 MRE-32SP074 MRE-G[ ]SP074 MRE-32SP097 MRE-G[ ]SP097 MRE-32SP101 MRE-G[ ]SP101...
- Page 3 - Be sure to store the controller in designed temperature and humidity CAUTION range, and do not exposed to direct sunlight. - Be sure to consult with NSD when the controller is stored for long - Be sure to handle the controller as industrial waste while periods.
- Page 4 * The Document No. appears at the upper right of this manual's cover page. Document No. Date Revision Description ZEF004479200 21, Dec., 2007 1st Edition Japanese document: ZEF004478601 ZEF004479201 28, Mar., 2008 2nd Edition Japanese document: ZEF004478602 Modification 6-2. Power Supply Connection 6-3.
-
Page 5: Table Of Contents
CONTENTS 1. SUMMARY ................................1 1-1. Features ................................1 2. MODEL SELECTION WHEN ORDERING ....................... 2 2-1. Model List ................................3 3. SPECIFICATIONS ..............................4 3-1. Converter Specifications ............................ 4 3-2. ABSOCODER Specifications ..........................6 3-3. Extension Sensor Cable Specification ....................... 9 4. -
Page 7: Summary
An origin returning operation is not required. (5) Superior durability NSD's original ABSOCODER is used as the position sensor which features a no-contact construction for excellent durability. This sensor offers problem-free operation, even in environments where it is exposed to vibration, impact shocks, extreme temperatures, oil, and dust. -
Page 8: Model Selection When Ordering
2. MODEL SELECTION WHEN ORDERING Indicates the configuration of NCV-20H. Before ordering, refer to the connection configure and model list. Please prepare by customer except 1 to 6 in the connection configuration. ●Connection configuration (1) Converter NCV-20HBNM2R NCV-20HGNM2R Connector at cable side (It is included in the converter.) MR-25F：Soldered socket... -
Page 9: Model List
2-1. Model List ◆Converter Model Descriptions NCV-20HBNM2R Position data binary code output (16bit) NCV-20HGNM2R Position data gray code output (16bit) ◆ABSOCODER Model Descriptions General environment type Mounting format: Flange-mount type With Interconnecting cable 2m MRE-[1]SP061FK[3] [1]: Total number of turns 32, G64, G128, G160, G256, G320 Compact size heavy duty type, SUS MRE-[1]SP074[2] K [3][L]-G... -
Page 10: Specifications
3. SPECIFICATIONS 3-1. Converter Specifications (1) General Specification Items Specifications ± Power supply voltage 24VDCV 10% (including ripple) Power consumption 7W or less 20 M-Ohms or more between external DC power terminals and ground Insulation resistance (by 500 VDC insulation resistance tester) 500 VAC, 60Hz for 1 minute between external DC power terminal and Withstand voltage ground... -
Page 11: Input/Output Specification
(3) Input / Output Specification Items Specifications Input signals HD (Position data HOLD): 1 point Input circuit DC input, photo-coupler isolation Input logic Negative logic ± Rated input voltage 24VDC Input Rated input current 10mA(24VDC) ON voltage 10VDC or more OFF voltage 4VDC or less D0 to D15 (Position data): 16 points... -
Page 12: Absocoder Specifications
3-2. ABSOCODER Specifications (1) MRE-[ ]SP061 Items Specifications MRE-[ ]SP061 Sensor model MRE-32SP061 [ ]: Total number of turns, and with a gear(G) or without gear [G64] [G128] [G160] [G256] [G320] Total number of turns Divisions / turn 2048 1024 409.6 204.8 Total number of divisions... - Page 13 (2) MRE-[ ]SP074 Items Specifications MRE-[ ]SP074 [ ]: Total number of turns, and with a gear(G) or without gear Sensor model [32] [G64] [G128] [G160] [G256] [G320] Total number of turns Divisions / turn 2048 1024 409.6 204.8 Total number of divisions 65536 (2 Mass 5.5+0.1 x cable length (m) kg...
- Page 14 (3) MRE-[ ]SP097 / MRE-[ ]SP101 Items Specifications MRE-[ ]SP097 / MRE-[ ]SP101 [ ]: Total number of turns, and with a gear (G) or without gear Sensor model [32] [G64] [G128] [G160] [G256] [G320] [G512] [G1280] [G2048] [G2560] [G3072] Total number of turns 1280 2048...
-
Page 15: Extension Sensor Cable Specification
8-core, 2 pairs without shield + 2 pairs with shield Color of sheath Gray Black Heat treatment and Extensible for long Advantage Superior flexibility; ideal for moving place flexible; ideal for distances moving place [Remark] Contact your NSD representative when the extension cable combines different types of cables. -
Page 16: Dimensions
4. DIMENSIONS 4-1. Converter Units: mm Mounting hole DIN rail... -
Page 17: Absocoder
4-2. ABSOCODER (1) MRE-32SP061FK[ ] (Flange-mounting type) Units: mm (2) MRE-G[ ]SP061FK[ ] (Flange-mount type) (3) MRE-[ ]SP074FK[ ][ ]-G (Flange-mount type) - Page 18 (4) MRE-[ ]SP074LK[ ][ ]-G (Base-mount type) Units: mm (5) MRE-[ ]SP074MK[ ][ ]-G (Face-mount type) (6) MRE-[ ]SP097FK[ ][ ]-G (Flange-mount type)
- Page 19 (7) MRE-[ ]SP097LK[ ][ ]-G(Base-mount type) Units: mm (8) MRE-[ ]SP101FK[ ][ ]-G (Flange-mount type) (9) MRE-[ ]SP101LK[ ][ ]-G (Base-mount type)
-
Page 20: Extension Sensor Cable
4-3. Extension Sensor Cable (1) 4P-S / RBT / URT-0144-[L] Units: mm ATTN: [L] is given in terms of meter. (2) 4P-S / RBT / URT / HRT-4344-[L] ATTN: [L] is given in terms of meter. (3) 4P-S / RBT / URT-0155-[L] ATTN: [L] is given in terms of meter. -
Page 21: Installation
5. INSTALLATION The installation conditions and precautions for each of the system components are described in this section. 5-1. Converter Installation Conditions and Precautions -Installation Site (1) Avoid sites where the unit is exposed to direct sunlight. (2) The ambient temperature should never exceed a 0 to 55°C range. (3) The ambient humidity should never exceed a 20 to 90% RH range. -
Page 22: Absocoder Installation Conditions And Precautions
5-2. ABSOCODER Installation Conditions and Precautions The installation conditions and precautions for ABSOCODER are described in this section. -Handling of Turn-type ABSOCODER Item Explanation 1) Main unit 2) Cable -Mounting of Turn-type ABSOCODER Item Explanation Precaution 1) Mounting For details regarding mounting dimensions, refer to each sensor dimensions. - Page 23 -Mounting of Turn-type ABSOCODER Item Explanation Precaution 1) Coupling of machine A “direct-link” format will shaft and sensor result in shaft fatigue shaft and / or breakage after long periods. Therefore, be sure to use a coupling device to link the shafts. 2) For gear-type linkage Incorrect gear mounting can result in shaft...
- Page 24 Mounting of Turn-type ABSOCODER Item Explanation Precaution 5) Shaft mounting position -Coupling of Turn-type ABSOCODER Item Explanation Precaution 1) Coupling device The selection of a selection precaution larger coupling than necessary will increase the shaft load which is caused by the mounting error amount.
-
Page 25: Ce Marking
5-3. CE Marking NCV-20H series conforms to CE Marking (EMC directive), but stands outside scope of the low voltage directive because it is 24 VDC power apparatus. 5-3-1. EMC Directives It is necessary to do CE marking in the customer’s responsibility in the state of a final product. Confirm EMC compliance of the machine and the entire device by customer because EMC changes configuration of the control panel, wiring, and layout. -
Page 26: Wiring
6. WIRING 6-1. Connection between Converter and ABSOCODER The maximum extension sensor cable length varies according to the ABSOCODER sensor and cable model being used. Please refer to the 3-2 for details. -Wiring Precautions (1) The sensor cable should be clamped as shown in the right figure to prevent excessive tension from being applied to the cable connectors. - Page 27 (2) In the case of using the commercially available cable (JKPEV-S 1.25mm ×5P) and connecting with crimping terminals Please install the crimping Converter terminals by customers JKPEV-S Cable cross section ABSOCODER sensor ommercially available cable Dedicated cable Crimping terminal (R1.25-4) Crimping Crimping terminal...
- Page 28 (3) In the case of using the commercially available cable (JKPEV-S 1.25mm ×5P) and connecting with a connector Please install the connector by customers. Converter JKPEV-S Cable cross ABSOCODER sensor ommercially available cable Dedicated cable Dedicated cable ABSOCODER sensor JKPEV-S cable connector pin arrangement connector pin arrangement connector pin arrangement and wire color...
-
Page 29: Power Supply Connection
6-2. Power Supply Connection The power supply should be connected as described below: (1) Power Supply -The rush current is 10A(rush time of 20ms), so select the power supply after due consideration. Over current Power +24VDC Choose the capacity of the power supply over protector Supply double of power consumption of converter. -
Page 30: Input / Output Connector Connection
6-3. Input / Output Connector Connection Lead wires should be soldered to pins of the connector according to the I/O chart below. Input / Signal Names Descriptions Output NCV-20HBNM2R: Output the position data by16 bit of binary code. NCV-20HGNM2R: Output the position data by16 bit of gray binary code. Output Position data D0 : LSB（Least Significant Bit）... - Page 31 ●I/O Circuit Converter internal circuit Input/output circuit is isolated from power supply and internal circuitry by photo-coupler. Use a Class 2 power supply for the input/output external power supply.
-
Page 32: Nomenclature
7. NOMENCLATURE 7-1. Part Identification Monitor LEDs -Position data output indicator -Sensor disconnection indicator -Latch pulse indicator -HOLD input indicator Power terminal block -M4 screw Current position value setting switch I/O connector Sensor connector 7-2. Function and Name of Display and Setting Area Rear face LED function for monitor Switch... -
Page 33: Operation
8. OPERATION 8-1. Operation Sequence START Function selector switch setting Designate the following setting by a switch which is at -------- Refer to section 8-2, 8-3. rear face of the converter. (1) Position data "increase direction" setting (2) Position data reading setting Converter mounting -------- Refer to section 5-1. -
Page 34: Position Data "Increase Direction" Setting
8-2. Position Data "Increase Direction" Setting The position data increases or decreases according to the ABSOCODER sensor's rotative direction. The direction in which the position data increases is specified by a switch on the converter's rear face. Switch setting Increase Switch setting Alteration of the position data direction... -
Page 35: Position Data Reading Setting
8-3. Position Data Reading Setting (1) Function setting switch list The following two position data reading formats are available: 1) Latch pulse (LP) format…Reads position data which is updated regularly in synchronization with a latch pulse output signal from the converter. 2) HOLD (HD) format…Reads position data while position data updates are stopped by a HOLD input signal. -
Page 36: Position Data Reading By Lp Output
(2) Position data reading by LP output Position data reading is synchronized with the LP output signal from the converter. Either high-speed or low-speed reading can be selected. ●High-speed reading When high-speed reading is selected, the position data output stabilizes at the trailing edge of the LP output signal. - Page 37 ●Low-speed reading (at LP=HIGH) When low-speed reading (at LP=HIGH) is selected, the position data output stabilizes when the LP output signal is HIGH. The position data should be read at that time. Position data update Switch setting cycle 12.8ms 12.8ms 3.2ms 6.4ms 25.6ms...
-
Page 38: Position Data Reading By Hold (Hd) Input
(3) Position data reading by HOLD (HD) input The HD input signal is used to HOLD position data outputs from the host controller. Either of the following 2 position data HOLD formats can be selected. ●Transparent format Position data output updating is stopped by an HD input signal from the host controller (PLC, etc.). The position data should be read at that time. -
Page 39: Current Position Setting
8-4. Current Position Setting The current position setting function changes the converter's position data output to a value that corresponds to the machine's current position. The position data can be changed to any desired value by using the rotary switch on the control panel. If an extension sensor cable is being used, the cable must be connected when performing the current position setting function. -
Page 40: For Gray Binary Code Output
(2) For gray binary code output <Current position setting procedure> 1) Secure the sensor to the machine, then move the machine to the desired position. 2) Obtain the position data that corresponds to the machine's current position. 3) Convert the position data obtained at step 2) above to gray binary code. 4) Use the control panel's rotary switches (in the D0 to D3 order) to specify monitor LED values that match the value converted at step 3) above. -
Page 41: Maintenance And Inspections
Check the signal. The wiring of the output signal has problems. Repair the wiring. If the troubleshooting procedures described above fail to solve the problem, the sensor or converter may be defective. In this case, please contact your NSD representative. -
Page 42: Absocoder Sensor Check List
10. ABSOCODER SENSOR CHECK LIST ● Applicable ABSOCODER sensor models MRE-32SP061, MRE-32SP074, MRE-32SP097, MRE-32SP101 MRE-G[ ]SP061, MRE-G[ ]SP074, MRE-G[ ]SP097, MRE-G[ ]SP101 ●Connection configuration Extension sensor cable ABSOCODER sensor Converter Commercially available cable JKPEV-S (1.25mm ×5P) ●Connector appearance and pin position View View View... - Page 43 Extension sensor cable resistance value The resistance value of the NSD special cable is 0.2Ω/m (loop resistance). The resistance value of the JKPEV-S cable is 0.034Ω/m (loop resistance). Consider resistance variations due to temperature, which, relative to the standard temperature (25 increases 0.4% when the temperature rises 1...
- Page 44 Manufacturer NSD Corporation 3-31-28, OSU, NAKA-KU, NAGOYA, JAPAN 460-8302 Distributor NSD Trading Corporation 3-31-23, OSU, NAKA-KU, NAGOYA, JAPAN 460-8302 Phone: +81-52-261-2352 Facsimile: +81-52-252-0522 URL: www.nsdcorp.com E-mail: foreign@nsdcorp.com Copyright©2020 NSD Corporation All rights reserved.
