●Signal names and descriptions
Signal name
D0
to
Position data
D25
LP
Latch pulse
NOR
System ready
ERR
Error
HD
HOLD
ZPS
Zero point setting
CLR
Error clear
P24
+24V common
Z24
0V common
NC
I/O
NCV-40HB[ ]M5: Outputs the position data by 26-bit of binary code.
NCV-40HG[ ]M5: Outputs the position data by 26-bit of gray code.
O
D0: LSB (Least Significant Bit), D25: MSB (Most Significant Bit)
Outputs the position data reading timing signal.
O
equipment can be synchronized with this signal to enable real-time
reading of position data.
O
The signal is turned OFF when the converter detects an error.
O
The signal is turned ON when the converter detects an error.
The HOLD input signal is used to HOLD position data outputs from the
I
host controller.
When this signal is switched ON (under error-free conditions), the
I
position data is set to "0" (zero set).
I
This signal is switched ON to recover from an error status.
Sink type: Power supply for input signals
I
Source type: Power supply for output signals
Sink type: 0V for output signals
I
Source type: 0V for input signals
Do not connect anything.
