● Other error contents
Error contents
Zero point deviation
Incorrect position
data output
Position data
HOLD doesn't
occur.
No position data
output
Probable cause
Coupling of ABSOCOER sensor shaft and the
Machine shaft is loose.
ABSOCODER sensor mounting is loose.
"ZPS"(the external input signal) is ON.
LP output signal and position data reading timing
are improper.
HD input signal and position data reading timing
are improper.
The wiring of the output signal has problems.
The function setting switch is incorrect.
The voltage of the power supply for input and
output is out of prescribed range.
The wiring of the input signal has problems.
The voltage of the power supply for input and
output is out of prescribed range.
The function setting switch is incorrect.
"ZPS"(the external input signal) is ON.
"HD"(the external input signal) is ON.
The wiring of the output signal has problems.
Secure the coupling / mounting.
Check the signal status.
Correct the reading timing.
Repair the wiring.
Change the setting.
Supply the correct power voltage.
10 to 30VDC
Repair the wiring.
Supply the correct power voltage.
10 to 30VDC
Change the setting.
Check the signal status.
Repair the wiring.
43
Error cancel procedures
