Chapter 2: Jumpers and Connectors

Speaker Connector

Connector type: 1.0mm Male 180D 1A SMD
Connector location: J3
6 1
Pin Definition
1 GND
2 ROUTP
3 ROUTN
4 GND
5 LOUTP
6 LOUTN
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Type Description
AUDIO_GND
O Right Output +
O Right Output -
AUDIO_GND
O Left Output +
O Left Output -

RTC Reset Connector

Connector type: 2.54mm Male 180D SMD
Connector location: JP1
1 3
Pin Definition
1 NC
2 RTC_RESET
3 GND
39
Type Description
O RTC Reset
Ground
