Chapter 2: Jumpers and Connectors
A38 GND
A39 SIP2
A40 SIN2
A41 GND
A42 GND
A43 SIP1
A44 SIN1
A45 GND
A46 GND
A47 SIP0
A48 SIN0
A49 GND
A50 GND
A51 GND
A52 GND
A53 GND
A54 GND
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Digital GND
Receiver Lane 2
I
Differential pair+
Receiver Lane 2
I
Differential pair-
Digital GND
Digital GND
Receiver Lane 1
I
Differential pair+
Receiver Lane 1
I
Differential pair-
Digital GND
Digital GND
Receiver Lane 0
I
Differential pair+
Receiver Lane 0
I
Differential pair-
Digital GND
Digital GND
Digital GND
Digital GND
Digital GND
Digital GND
B38 SON2
B39 GND
B40 GND
B41 SOP1
B42 SON1
B43 GND
B44 GND
B45 SOP0
B46 SON0
B47 GND
B48 PRSNT#2
B49 GND
B50 GND
B51 GND
B52 3VSB
B53 3VSB
B54 3VSB
67
Transmitter Lane 2,
O
Differential pair-
Digital GND
Digital GND
Transmitter Lane 1,
O
Differential pair+
Transmitter Lane 1,
O
Differential pair-
Digital GND
Digital GND
Transmitter Lane 0,
O
Differential pair+
Transmitter Lane 0,
O
Differential pair-
Digital GND
Hot plug detect
Digital GND
Digital GND
Digital GND
O 3.3V
O 3.3V
O 3.3V
