Chapter 2: Jumpers and Connectors
A15 GND
A16 SIP7
A17 SIN7
A18 GND
A19 NA
A20 GND
A21 SIP6
A22 SIN6
A23 GND
A24 GND
A25 SIP5
A26 SIN5
A27 GND
A28 GND
A29 SIP4
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Digital GND
Receiver Lane 7
I
Differential pair+
Receiver Lane 7
I
Differential pair-
Digital GND
NA
Digital GND
Receiver Lane 6
I
Differential pair+
Receiver Lane 6
I
Differential pair-
Digital GND
Digital GND
Receiver Lane 5
I
Differential pair+
Receiver Lane 5
I
Differential pair-
Digital GND
Digital GND
Receiver Lane 4
I
Differential pair+
B15 SON7
B16 GND
B17 PRSNT#2
B18 GND
B19 SOP6
B20 SON6
B21 GND
B22 GND
B23 SOP5
B24 SON5
B25 GND
B26 GND
B27 SOP4
B28 SON4
B29 GND
34
Transmitter Lane 7,
O
Differential pair-
Digital GND
O Hotplug detect
Digital GND
Transmitter Lane 6,
O
Differential pair+
Transmitter Lane 6,
O
Differential pair-
Digital GND
Digital GND
Transmitter Lane 5,
O
Differential pair+
Transmitter Lane 5,
O
Differential pair-
Digital GND
Digital GND
Transmitter Lane 4,
O
Differential pair+
Transmitter Lane,
O
Differential pair-
Digital GND
Continued on the next page
