Chapter 2: Jumpers and Connectors

LED Housing

Connector type: GRE(LED1)YEL(LED2) H: 9.65mm 90D DIP
Connector location: LED1
C2 C1
A2 A1
Pin Definition
A1 LED+
A2 LED+
C1 LED-
C2 LED-
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Type Description
GREEN LED Postive
O YELLOW LED Postive
GREEN LED Minus
YELLOW LED Minus

Power Button Connector

Connector type: DC12V 50mA DIP 8P 90D w/LED
Connector location: SW1
4 A1
1
2
3 C1
Pin Definition
1 GND
2 ATX Button
3 ATX Button
4 GND
A1 LED+
C1 LED-
Lights blue when power is on, lights red when power is off.
50
Blue/Red
Type Description
A contact
O B contact
B contact
A contact
LED Plus
LED Minus
