Chapter 2: Jumpers and Connectors
29 PCIE_RX6N
31 PCIE_RX6P
33 GND
35 PCIE_TX6N
37 PCIE_TX6P
39 GND
41 SATA_0BRXP
43 SATA_0BRXN
45 GND
47 SATA_0BTXN
49 SATA_0BTXP
51 GND
53 PCIE_CLK_15N
55 PCIE_CLK_15P
57 GND
59 NC
61 NC
63 NC
65 NC
67 M2_PLTRST#
69 CFG1
71 GND
73 GND
75 CFG2
The CN5 and CN6 connectors are alternative options to connect peripheral devices, only one connector can be used at a time.
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
BI PERN
BI PERP
Digital Ground
BI PETN
BI PETP
Digital Ground
BI SATAB+
BI SATAB-
Digital Ground
BI SATAA-
BI SATAA+
Digital Ground
BI REFCLKN
BI REFCLKP
Digital Ground
NC
NC
NC
NC
O RESET#
I CONFIG1
Digital Ground
Digital Ground
I CONFIG2
30 NC
32 NC
34 NC
36 NC
38 SATA_DEVSLP2
40 NC
42 NC
44 NC
46 NC
48 NC
50 RESET#
52 SRCCLKREQ15
54 WAKE#
56 NC
58 NC
60 NC
62 NC
64 NC
66 NC
68 I_SUSCLK
70 3VSB
72 3VSB
74 3VSB
30
NC
NC
NC
NC
O DEVSLP
NC
NC
NC
NC
NC
I PERST#
O CLKREQ#
O PEWAKE#
NC
NC
NC
NC
NC
NC
BI SUSCLK
O +3.3V
O +3.3V
O +3.3V
