Chapter 3: System Setup
3.
Insert the M.2 module into the M.2 slot at 45-degree angle until the
gold-plated connector on the edge of the module completely disappears
into the slot.
M.2 Key B module
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Bracket for M.2 module
with a length of 42mm
4.
Push the module down and secure it with a screw.
78
IPPC XX11-C11 Series User Manual
