Chapter 2: Jumpers and Connectors
Panel PWM Voltage Selection
Connector type: 2.54mm H:8.5mm Male 180D
Connector location: JP2
1
3
Pin
Definition
1-2
VCC3
2-3
VCC5
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Type
Description
O
3.3V
O
5V
Panel Power Selection
Connector type: 2.54mm H:8.5mm Male 180D
Connector location: JP3
1
3
Pin
Definition
1-2
VCC3
2-3
VCC5
53
Type
Description
O
3.3V
O
5V
IPPC XX11-C11 Series User Manual
