Chapter 2: Jumpers and Connectors
29 USB3_RX8N
31 USB3_RX8P
33 GND
35 USB_TX8N
37 USB_TX8P
39 GND
41 PCIE_RX7N
43 PCIE_RX7P
45 GND
47 PCIE_TX7N
49 PCIE_TX7P
51 GND
53 PCIE_CLK_14N
55 PCIE_CLK_14P
57 GND
59 NC
61 NC
63 NC
65 NC
67 M2_PLTRST#
69 CFG1
71 GND
73 GND
75 CFG2
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
BI USB3_RX-
BI USB3_RX+
Digital Ground
BI USB3_TX-
BI USB3_TX+
Digital Ground
BI PERN0
BI PERP0
Digital Ground
BI PETN0
BI PETP0
Digital Ground
BI REFCLKN
BI REFCLKP
Digital Ground
NC
NC
NC
NC
O RESET#
I CONFIG1
Digital Ground
Digital Ground
I CONFIG2
30 UIMRESET
32 UIMCLK
34 UIMDATA
36 UIMPWR
38 SATA_DEVSLP3
40 NC
42 NC
44 NC
46 NC
48 NC
50 RESET#
52 SRCCLKREQ14
54 WAKE#
56 NC
58 NC
60 NC
62 NC
64 NC
66 NC
68 I_SUSCLK
70 3VSB
72 3VSB
74 3VSB
27
O UIM_RESET
O UIM-CLK
BI UIM-DATA
O UIM-PWR
O DEVSLP
NC
NC
NC
NC
NC
I PERST#
O CLKREQ#
O PEWAKE#
NC
NC
NC
NC
NC
NC
BI SUSCLK
O +3.3V
O +3.3V
O +3.3V
