Chapter 4: BIOS Setup
Trusted Computing
This section is used to configure Trusted Platform Module (TPM) settings.
Aptio Setup Utility - AMI
Advanced
TPM20 Device Found
Firmware Version: 7.62
Vendor: IFX
Security Device Support [Enable]
Active PCR banks SHA256
Available PCR banks SHA-1, SHA256
SHA-1 PCR Bank [Disabled]
SHA256 PCR Bank [Enabled]
Pending operation [None]
Platform Hierarchy [Enabled]
Storage Hierarchy [Enabled]
Endorsement Hierarchy [Enabled]
TPM2.0 UEFI Spec Version [TCG_2]
Physical Presence Spec Version [1.3]
TPM 20 InterfaceType [TIS]
Device Select [Auto]
Version 2.21.1278. Copyright (C) 2022 AMI
Security Device Support
Enable or disable BIOS support for security device. O.S will not show
Security Device. TCG EFI protocol and INT1A interface will not be available.
SHA-1 PCR Bank
Enable or disable SHA-1 PCR Bank.
SHA256 PCR Bank
Enable or disable SHA256 PCR Bank.
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pending operation
Schedule an operation for the security device. Note that your device will
reboot during restart in order to change State of Security Device.
Platform Hierarchy
Enable or disable platform hierarchy.
Enables or Disables BIOS sup-
port for security device.
O.S. will not show Security
Device. TCG EFI protocol and
Storage Hierarchy
INT1A interface will not be
available.
Enable or disable storage hierarchy.
Endorsement Hierarchy
Enable or disable endorsement hierarchy.
TPM2.0 UEFI Spec Version
→←: Select Screen
Configure the TPM 2.0 UEFI spec version.
↑↓: Select Item
Enter: Select
TCG_1_2: Compatible mode for Win8/WIn10.
+/-: Change Opt.
F1: General Help
TCG_2:
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Physical Presence Spec Version
Configure the physical presence spec version. Note that some HCK tests
might not support 1.3.
Device Select
Configure the TPM version. TPM 1.2 will restrict support to TPM 1.2 devices
and TPM 2.0 will restrict support to TPM 2.0 devices. Auto will support
both TPM 1.2 and 2.0 devices with the default set to TPM 2.0 devices if not
found, and TPM 1.2 devices will be enumerated.
96
Support new TGG2 protocol and event format for Win10 or later.
