Chapter 2: Jumpers and Connectors

USB2.0 Port / I2C Connector

Connector type: 2.0mm Male 180D SMD
Connector location: CN7
9 1
10 2
Pin Definition
1 LINE_L
2 LINE_OUT_L
3 LINE_R
4 LINE_OUT_R
5 LININ_JD
6 LINE2_JD
7 GND
8 GND
9 GND
10 GND
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Type Description
O LINE Input Left
O LINE Output Left
BI LINE Input Right
O LINE Output Right
BI LINE Input detect
BI LINE Output detect
AUDIO_GND
AUDIO_GND
AUDIO_GND
AUDIO_GND
USB2.0 Port / I2C Connector
Connector type: 2.0mm Male 180D SMD
Connector location: CN8
9 1
10 2
Pin Definition
1 +5V
2 GND
3 USB2_N4
4 USB2_P5
5 USB2_P4
6 USB2_N5
7 GND
8 +5V
9 I2C_CLK
10 I2C_DAT
38
Type Description
O USB Port1 5V Power
Digital GND
BI USB2 Port4 DN signal
BI USB2 Port5 DP signal
BI USB2 Port4 DP signal
BI USB2 Port5 DN signal
Digital GND
O USB Port1 5V Power
BI I2C Clock
BI I2C Data
