Chapter 3: System Setup
3.
Follow the illustrations below to mount the system to the top panel,
then tighten the mounting kit screws.
Less than 3mm
Top Panel
Panel Mount Kit
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
4.
Follow the previous procedure to mount the system to the bottom
panel. Ensure that all screws are tightened.
Bottom Panel
Less than 3mm
87
IPPC XX11-C11 Series User Manual
