Nexcom IPPC 11-C11 Series User Manual page 53

Chapter 2: Jumpers and Connectors
A30 SIN4
A31 GND
A32 NA
A33 NA
A34 GND
A35 SIP3
A36 SIN3
A37 GND
A38 GND
A39 SIP2
A40 SIN2
A41 GND
A42 GND
A43 SIP1
A44 SIN1
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Receiver Lane 4
I
Differential pair-
Digital GND
NA
NA
Digital GND
Receiver Lane 3
I
Differential pair+
Receiver Lane 3
I
Differential pair-
Digital GND
Digital GND
Receiver Lane 2
I
Differential pair+
Receiver Lane 2
I
Differential pair-
Digital GND
Digital GND
Receiver Lane 1
I
Differential pair+
Receiver Lane 1
I
Differential pair-
B30 NA
B31 PRSNT#2
B32 GND
B33 SOP3
B34 SON3
B35 GND
B36 GND
B37 SOP2
B38 SON2
B39 GND
B40 GND
B41 SOP1
B42 SON1
B43 GND
B44 GND
35
NA
O Hot plug detect
Digital GND
Transmitter Lane 3,
O
Differential pair+
Transmitter Lane 3,
O
Differential pair-
Digital GND
Digital GND
Transmitter Lane 2,
O
Differential pair+
Transmitter Lane 2,
O
Differential pair-
Digital GND
Digital GND
Transmitter Lane 1,
O
Differential pair+
Transmitter Lane 1,
O
Differential pair-
Digital GND
Digital GND
Continued on the next page
