Chapter 4: BIOS Setup
Hardware Monitor
This section is used to monitor hardware status such as temperature, fan
speed, and voltages.
Aptio Setup Utility - AMI
Advanced
Pc Health Status
System temperature : +33
CPU temperature : +30
Fan Speed : N/A
: +12.123 V
+12V
+5V : +5.100 V
+3.3V : +3.31 V
VCORE : +0.800 V
Version 2.21.1278. Copyright (C) 2022 AMI
System Temperature
Detect and display the current system temperature.
CPU Temperature
Detect and display the current CPU temperature.
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
0 C
C
0
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Fan Speed
Detect and display the system fan speed.
VCore
Detect and display the Vcore CPU voltage.
