Chapter 2: Jumpers and Connectors
Resistance Touch Connector
Connector type: 6P 180D Male SMD 5x6, 4x8mm
Connector location: FUSB1
6
1
Pin
Definition
1
+5V
2
+5V
3
USB_N
4
USB_P
5
GND
6
GND
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Type
Description
O
USB Port 5V Power
O
USB Port 5V Power
BI
USB Port DN signal
BI
USB Port DP signal
GROUND
GROUND
58
IPPC XX11-C11 Series User Manual
