Chapter 3: System Setup
Installing a mini-PCIe Module
1.
Locate the mini-PCIe slot on the motherboard.
The M.2 slot (CN5) that overlaps with the miniPCIe (CN6) slot
is alternate.
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
2.
Install the mini-PCIe bracket to the mini-PCIe module (When using a
half-size module).
Screws
79
IPPC XX11-C11 Series User Manual
