Chapter 2: Jumpers and Connectors

PWM / CCFL DIP Switch

Connector type: 4P 4.1x8x2.5 mm
Connector location: SW1
1 4
2 3
Mode CCFL Mode
SW2-1 OFF
SW2-2 ON
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
PWM Mode
ON
OFF

eDP/LVDS Function DIP Switch

Connector type: 2P 2.5x8x2.5 mm
Connector location: U9
2 1
Pin Definition
1 OFF
2 ON
54
Type Description
O eDP (HIGH)
O LVDS (LOW)
IPPC XX11-C11 Series User Manual
