Chapter 2: Jumpers and Connectors
A55 S_USB2_OC#7
A56 GND
A57 USB2_8N
A58 USB2_8P
A59 GND
A60 GND
A61 USB2_9N
A62 USB2_9P
A63 GND
A64 GND
A65 GND
A66 GND
A67 eDP_VDDEN
A68 eDP_TXN0
A69 eDP_TXP0
A70 eDP_TXN1
A71 eDP_TXP1
A72 eDP_TXN2
A73 eDP_TXP2
A74 eDP_TXN3
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
O USB OC
Digital GND
BI USB Port DN signal
BI USB Port DP signal
Digital GND
Digital GND
BI USB Port DN signal
BI USB Port DP signal
Digital GND
Digital GND
Digital GND
Digital GND
eDP Power Enable
embedded DisplayPort*
O
Transmit
embedded DisplayPort*
O
Transmit
embedded DisplayPort*
O
Transmit
embedded DisplayPort*
O
Transmit
embedded DisplayPort*
O
Transmit
embedded DisplayPort*
O
Transmit
embedded DisplayPort*
O
Transmit
B55 3VSB
B56 VCC3
B57 VCC3
B58 VCC3
B59 VCC3
B60 VCC3
B61 VCC3
B62 GND
B63 PWROK
B64 GND
B65 NA
B66 ESPICLK
B67 ESPI_CS1#
B68 ESPI0
B69 ESPI1
B70 ESPI2
B71 ESPI3
B72 ESPI_ALERT
B73 ESPI_RST
B74 GND
68
O 3.3V
O 3.3V
O 3.3V
O 3.3V
O 3.3V
O 3.3V
O 3.3V
Digital GND
O Power OK
Digital GND
NA
O eSPI Clock
O eSPI chip selects
BI Bi-directional data signals
BI Bi-directional data signals
BI Bi-directional data signals
BI Bi-directional data signals
O ESPI Alert
O eSPI reset
Digital GND
