Chapter 1: Product Introduction
Knowing Your IPPC 2411-C11
Rear Bottom
7
1 2
3
4
5
6 8
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
1. Power Switch
Press to turn or off the power.
2. Remote Power Switch
Connect a remote to power on or off the system.
3. DC Input (24VDC)
Connect a DC power cord.
4. USB 3.1
Connect to USB 3.0/2.0 devices.
5. GbE LAN Ports
Connect to a local area network (both ports support Wake Up on LAN).
6. DisplayPort
Connect to a DisplayPort monitor (version 1.2,
resolution up to 4096x2160 @60Hz).
7.
Storage Driver
Signal LED
Lights up in yellow when a 2.5" storage device is connected.
8. GPIO Programmable LED
Define the LED by the user.
16
IPPC XX11-C11 Series User Manual
