Chapter 2: Jumpers and Connectors

LVDS / eDP Connector

Connector type: 20P 1.25mm Male 180D DIP
Connector location: LVDS1
2
20
19 1
Pin Definition
1 CH_GPIO0
2 CH_GPIO1
3 VCCLCD
4 LVDS_DAT0P
5 LVDS_DAT3P
6 LVDS_DAT0N
7 LVDS_DAT03N
8 VCCLCD
9 GND
10 LVDS_DAT1P
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Type Description
O GPIO
O GPIO
O LCD POWER
O LVDS DATA0P/eDP_HPD
O DATA3P
O DATA0N
O DATA3N
O LCD POWER
GROUND
O LVDS DATA1P/eDP_TX1P
Pin Definition
11 LVDS_CLK1P
12 LVDS_DAT1N
13 LVDS_CLK1N
14 GND
15 GND
16 V_INV
17 LVDS_DAT2P
18 V_INV
19 LVDS_DAT2N
20 GND
62
Type Description
O LVDS CLK1P/ eDP_AUXP
O LVDS DATA1N/ eDP_TX1P
O LVDS CLK1N/ eDP_AUXN
GROUND
GROUND
O 12V
O LVDS DATA2P/ eDP_TX0P
O 12V
LVDS DATA2N/ eDP_
O
TX0N
GROUND
