Chapter 2: Jumpers and Connectors

M.2 Key B Connector

Connector type: SMD H: 8.5mm 90D Gold Flash Pit: 0.5mm
Connector singal: PCIe x1, USB 3.0, USB 2.0, SIM
Connector location: CN3
74 2
75 1
Pin Definition
1 CFG1
3 GND
5 GND
7 USB11P
9 USB11N
11 GND
13 NC
15 NC
17 NC
19 NC
21 CFG0
23 WAKE#
25 NC
27 GND
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Type Description
I CONFIG3
Digital Ground
Digital Ground
BI USBD+
BI USBD-
REFCLK-
NC
NC
NC
NC
I CONFIG0
O GPIO_11
NC
Digital Ground
Pin Definition
2 3VSB
4 3VSB
6 PWROFF#
8 M2TEDISL#
10 NC
12 NC
14 NC
16 NC
18 NC
20 NC
22 NC
24 NC
26 NC
28 UIMVPP
26
Type Description
O +3.3V
O +3.3V
I POWER_OFF#
I W_DISABLE#
NC
NC
NC
NC
NC
NC
NC
NC
NC
O GPIO_8
Continued on the next page
