Chapter 2: Jumpers and Connectors
29 GND
31 PCIE_mSATA_TXN
33 PCIE_mSATA_TXP
35 GND
37 GND
39 3VSB
41 3VSB
43 GND
45 NC
47 NC
49 NC
51 SEL
The CN5 and CN6 connectors are alternative options to connect peripheral devices, only one connector can be used at a time.
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
CHASIS_ GND
BI PETN0/SATATXN
BI PETP0/SATATXP
CHASIS_ GND
CHASIS_ GND
O 3.3V
O 3.3V
CHASIS_ GND
NC
NC
NC
O PCIE/mSATA detect
30 SMB_CLK
32 SMB_DAT
34 GND
36 USB_7N
38 USB_7P
40 GND
42 NC
44 NC
46 NC
48 VCC1V5
50 GND
52 3VSB
32
BI SMBUS CLK
BI SMBUS DATA
CHASIS_ GND
BI USBD-
BI USBD+
CHASIS_ GND
NC
NC
NC
O 1.5V
CHASIS_ GND
O 3.3V
