Digital SmartHandle AX
(Manual)
5. For 7 mm spindle: place the adapter sleeve in the inner handle in such a
way that the recess faces the grub screw.
6. Determine your inner handle's direction rotation as viewed from the in-
side: clockwise (clockwise = CW) or anti-clockwise (counter-clockwise
= CCW).
7.. Installation
64 / 296
