Reader Technology; Access Control (Zk) And Time Zone Control - Simons Voss Technologies Digital SmartHandle AX A0 Manual

Digital SmartHandle AX

6.11 Reader technology

6.12 Access control (ZK) and time zone control

(Manual)
Depending on the equipment, your SmartHandle AX supports the following
scanning methods:
Active (25 kHz) - initial programming also possible passively

Passive (MIFARE Classic, Plus, DESFire )

Hybrid (active and passive in one SmartHandle AX)

BLE (Bluetooth Low Energy. SmartHandle AX is prepared and can be

retrofitted after release)
The double-sided reading variant is a special version of the upright
SmartHandle AX that can be combined with an additional upright
SmartHandle AX to create a double-sided reading escutcheon.
NOTE
Active and hybrid technology only with shortened range
The active and hybrid technologies have a significantly greater range. Un-
der normal operating conditions, both SmartHandle AX are reached at the
same time and communication errors may occur.
Activate the checkbox for a shortened range for both sides on the

SmartHandle AX in LSM/AXM.
Alternatively, it is SmartHandle AX also available without electronics or
permanent coupling.
Access Control
With this option, your SmartHandle AX can store up to 1500 accesses.
A saved entry consists of:
Date

Time

Transponder ID (TID)

You can read this data at any time with a programming device or via the
network and thus trace which transponder was used when to operate the
SmartHandle AX.
Time zone control
In addition, the time zone option also allows you to control the time zone.
You can then program your SmartHandle AX in such a way that certain
identification media are only authorised for access at certain times. You
6.. Versions
21 / 296
