Digital SmartHandle AX

6.4 Distances and door thicknesses

(Manual)
Fastening
Rosette fastening with
(optional) mechanical
override
Mounting on a tubular
frame with (optional)
mechanical override
Rosette fastening with
panic bar adaptation
Backplate mounting
A* = Euro Profile, B* = Swiss Round, E* = Scandinavian Oval
Variant A0

(Standing
installation) [ 23]
}
Variant A1 and A2

(suspended
installation) [ 75]
}
Variant DS (reader

on both sides)
[ 172]
}
Variants E0 and E1

(Scandinavian Oval)
[ 200]
}
Variant A0.PAS

(Standing assembly
with PAS24)
[ 48]
}
Variant A3 (tubular
frame) [ 103]
}
Variant A4.P11

(panic bar CISA)
[ 129]
}
Variant A4.P1/A4.P2

(BKS panic bar)
[ 150]
}
Variant F1 (French 195
mm backplate) [ 217]
}
6.. Versions
15 / 296
You fasten the Smart-
Handle AX through the
drill holes and holes
provided in the mortise
lock.
You fasten the Smart-
Handle AX to adapter
plates. These adapter
plates are screwed
onto the tubular frame
using rivet nuts.
You fasten the using
adapter SmartHandle
AX plates through drill
holes and the holes
provided in the mortise
lock. A panic bar, which
must be ordered separ-
ately, can then be fitted
on the inner side.
You attach the Smart-
Handle AX through the
drill holes of adapter
plates.
