Digital SmartHandle AX (Manual)
Handle and square spindle
Order code
S2.LEVER.x.x
S2.SQUARE.x.x
SH.HUELSE.8.5
Description
Inner side and outer side handle for
Handle variants
retrofitting (see
[ 19] ).
}
Please specify variant:
A

В

C

D

L

Please specify square spindle (see
Spindle [ 17]
):
}
7 mm

8 mm

9 mm

Please specify length of square
spindle (see Distances and door
thicknesses [ 15]
):
}
S

M

L

X

Please specify diameter (see
Spindle [ 17] ):
}
7 mm

8 mm

9 mm

Extension sleeve from 8 mm to
8.5 mm length (10 pieces)
17.. Accessories
