Digital SmartHandle AX
Effect on the mortise lock
The SmartHandle AX acts exclusively on the latch of the mortise lock.
Locking and insurances
Insurance companies place increased demands on a closure.
1. If you want to lock the door under insurance law, use a self-locking panic lock or a locking
cylinder in addition to the SmartHandle AX.
2. Pay attention to the approvals according to EN 179.
SmartHandle AX with self-locking panic lock
The SmartHandle AX only offers full functionality with a self-locking panic lock.
1. Combine the SmartHandle AX with a self-locking panic lock.
2. Pay attention to the declarations of conformity of the lock manufacturers according to EN
179.
Conditions for authorisation security
Operation with Mifare Classic and/or PinCode keypad excludes authorisation security class D ac-
cording to DIN EN 16867:2020.
Sealing escutcheon holes
Any escutcheon holes that exist may be used to manipulate the lock.
1. Seal any escutcheon holes with a blind cylinder, for example.
2. In the case of FH versions, you must be install a brass dummy cylinder or locking cylinder.
7.3.2 Scope of delivery
(Manual)
NOTE
Incorrect installation
SimonsVoss Technologies GmbH accepts no liability for damage caused to
doors or components due to incorrect fitting or installation.
SmartHandle AX (suspended installation for PAS24)
Special tool
Quick guide
Depending on version:
Adapter set, 7 mm spindle
Adapter sleeve, 8.5 mm spindle
Adapter sleeve, 10 mm spindle
Blank cylinder
7.. Installation
49 / 296
