Digital SmartHandle AX
7. Installation
7.1 Installation instructions
7.2 Variant A0 (Standing installation)
7.2.1 Product-specific safety instructions
IMPORTANT
Damage by drilling
You drill at your own risk. SimonsVoss Technologies GmbH is not liable for damage caused by
drilling.
Please also observe the safety instructions of the drilling machine.
Damage caused by unsuitable tools
If you try to open the case with unsuitable tools, the case may be damaged.
Use only the supplied SimonsVoss opening tool.
Loss of the precise guidance of the handle
It may be difficult to install on mortise locks with a retaining nut.
Do not mechanically alter the locking nut. The handle would then lose its precise guidance.
Difficult installation due to inaccurate holes
The fitting cannot be installed if the fastening holes and the spindle do not match.
Make sure that the fastening holes and the spindle are in parallel vertical lines.
(Manual)
You can programme the SmartHandle AX while it is still in the packaging
(except MP) and then install it.
You will also find information on installing the SmartHandle AX in the
accompanying quick guide.
The batteries are already fitted.
Do not touch electronics/components; do not allow them to come into
contact with oil, paint, moisture, alkali or acids.
Keep away from sources of interference, such as power supply units.
You must not strike the product while installing the cylinder.
Attach plan to the door. Do not install while bent or tensioned.
Use the supplied drilling template.
If required, fit the supplied dummy cylinder to comply with approval
requirements for FH variants.
Only undo the indicated screws.
7.. Installation
23 / 296
