Digital SmartHandle AX

7.8 Variant DS (reader on both sides)

7.8.1 Product-specific safety instructions

IMPORTANT
Damage by drilling
You drill at your own risk. SimonsVoss Technologies GmbH is not liable for damage caused by
drilling.
Please also observe the safety instructions of the drilling machine.

Damage caused by unsuitable tools
If you try to open the case with unsuitable tools, the case may be damaged.
Use only the supplied SimonsVoss opening tool.

Loss of the precise guidance of the handle
It may be difficult to install on mortise locks with a retaining nut.
Do not mechanically alter the locking nut. The handle would then lose its precise guidance.

Difficult installation due to inaccurate holes
The fitting cannot be installed if the fastening holes and the spindle do not match.
Make sure that the fastening holes and the spindle are in parallel vertical lines.

Incorrect installation
SimonsVoss Technologies GmbH accepts no liability for damage caused to doors or compon-
ents due to incorrect fitting or installation.
Effect on the mortise lock
The SmartHandle AX acts exclusively on the latch of the mortise lock.
Locking and insurances
Insurance companies place increased demands on a closure.
1. If you want to lock the door under insurance law, use a self-locking panic lock or a locking
cylinder in addition to the SmartHandle AX.
2. Pay attention to the approvals according to EN 179.
(Manual)
NOTE
Active and hybrid technology only with shortened range
The active and hybrid technologies have a significantly greater range. Un-
der normal operating conditions, both SmartHandle AX are reached at the
same time and communication errors may occur.
Activate the checkbox for a shortened range for both sides on the

SmartHandle AX in LSM/AXM.
7.. Installation
172 / 296
