Digital SmartHandle AX
8. Programming
(Manual)
The configuration is described in the LSM, but is also included in the AXM in
a similar form.
Current version of LSM/AXM installed.
ü
NOTE
Compatibility between driver and firmware
To use MIFARE DESFire ident media with a SmartHandle AX with firmware
version 1.1.604 or higher, the SV driver 7.27 (from LSM 3.5) or higher is re-
quired.
LSM open.
ü
SmartStick AX, SmartCD.MP or SmartCD2.G2 connected
ü
(recommendation: SmartStick AX).
1. Select the locking system that you require. Use the ... button to open
the locking system properties and use the
the required lock system.
2. Click on the button to add a new locking device.
The "New lock" window will open.
9
3. Open the ▼ Area drop-down menu.
4. Select the area.
5. Open the drop-down menu ▼ Lock type.
6. Select the "AX SmartHandle" item.
7. Complete the rest of the form.
8. Click the button Save & next .
9 Locking device has been added.
9. Click on the Exit button.
Window closes.
9
10. Highlight the entry on the SmartHandle AX in the matrix.
11. Tap SmartStick AX on or SmartHandle AX to align with SmartCD.MP
SmartHandle AX or position SmartCD.G2 about ten centimetres from
SmartHandle AX.
8.. Programming
242 / 296
and buttons to select
