Remote Session
Control Panel
Speaker – Click to toggle sound On and Off from the
remote server to be heard on the client computer's speakers.
Macro List – Click this icon to display a drop-down list of
the User Macros (see User Macros section under Control Panel
for details) that have been added to the KVM switch. Select a
macro to run it on the selected computer.
Scan Ports – Click to initiate Auto Scan mode. (See Auto
Scanning section for details.)
Array Mode – Click to initiate Panel Array mode. (See
Panel Array Mode section under The OSD Toolbar for details.)
Open GUI – Click to open the OSD.
Customize Control Panel – Click this icon to bring
up the Customize Control Panel screen, which allows you to
choose which icons are displayed in the control panel, as well
as edit some of its features.
Customize Control Panel – The box on the left side of the
screen displays a list of the available control panel features,
with a checkbox next to each one. Check/uncheck a checkbox
to display or remove the corresponding features icon from
the control panel. By default, all features are included in the
control panel.
Control Panel Style – This section allows you to determine
how the control panel is displayed when it is dragged out of
the default position in the top-center of the screen.
Note: There is a second default position for the control panel at the
bottom-center of the screen.
• When the Transparent checkbox is checked, dragging the
control panel away from one of the default locations will
leave it displayed transparently in whatever location it was
dragged to.
• When the Icon checkbox is checked, dragging the control
panel away from one of the default locations will leave it
displayed as an icon in whatever location it was dragged to.
• When both the Transparent and Icon checkboxes are
checked, dragging the control panel away from one of the
default locations will leave it displayed as a transparent icon
in whatever location it was dragged to.
• When neither checkbox is checked, dragging the control
panel away from one of the default locations will leave it
displayed as normal in whatever location it was dragged to.
• If the control panel is located in either the top-center or
bottom-center default locations, checking these checkboxes
will have no effect.
