OSD Operation

Log

The B064-Series KVM switch logs all the events that take place and writes them to a log file. The Log section is split into two sub-
sections; Log Information and Notification Settings.
Log Information
The Log Information sub-section is where you can view the
contents of the built-in log file. When opened, a page similar to
the one below appears.
Field
Time
Information
User
Priority
Reset
Exit
Notification Settings
The Notification Settings sub-section allows you to select which events are sent out to SNMP, SMTP and SysLog servers. Simply check
the checkboxes in the rows of the events that you want notifications sent out for, and in the column(s) of the methods you want
them to be sent to. When checked, the corresponding event notification will be sent using the corresponding method.
Note: Notifications default with an "X", which means they are disabled. Click on a notification box to mark it with a check, enabling it. You can check
multiple boxes at the same time using the [Shift] or [Ctrl] keys. To highlight a group of consecutive ports, start by highlighting the first port, hold down
the [Shift] key, and then highlight the last port that you wish to highlight. All ports from the first one you highlighted to the last will be highlighted. You can
then click on any of the permission checkboxes to change that permission for all of the highlighted ports. To highlight multiple non-consecutive ports,
start by highlighting the first port, hold down the [Ctrl] key, and then highlight each additional port one by one while continuing to hold down the [Ctrl]
key. When all of the desired ports are highlighted, click on any checkbox to change that permission for all of the highlighted ports.
56
Example
The Time filter settings allow you to display only those records that occurred at a specific time. Below
are the options.
• Today Only – Check the Today Only checkbox and click the Apply button to display only those
events that occurred on today's date.
• Device Time – Shows the events according to the time configuration on the switch.
• Start Date/Time – Check the Start Date/Time checkbox and click in the field to the right of it to bring
up a calendar that allows you to select a desired date and time. Click the Apply button to display all
of the events that occurred between the date/time entered into the Start Date/Time field and the
present date/time.
• End Date/Time – This setting works in conjunction with the Start Date/Time field. Check the Start
Date/Time checkbox and click in the field to the right of it to bring up a calendar that allows you to
select a desired date and time. Check the End Date/Time checkbox and click in the field to the right
of it to bring up a calendar that allows you to select a desired date and time. Click the Apply button
to display all of the events that occurred between the date/time entered into the Start Date/Time
field and the date/time entered into the End Date/Time field.
The Information field allows you to type in a key word or string, and display only those records that
contain the search term. Simply type in a search term and click the Apply button.
The User field allows you to type in a user name, and display only those records that contain the text that
you entered in the User field. To filter by User, you must check the User checkbox, type in a search term,
and then click the Apply button.
The Priority fields allow you to filter by the Priority of the event being recorded; Least, Less or Most. To
filter by Priority, check the Priority checkbox, then check the Priority level checkbox(es) that you wish to
filter by, and then click the Apply button.
Click the Reset button at any time to clear any filter settings that were entered and display all events.
Click the Exit button to close the Filter settings.
The Log Information page can store up to 512 events, at which
time the oldest files are deleted and replaced with newer files.
The records it displays show the Time, Severity, User and Log
Information associated with the event. At the bottom of the
screen are four icons, whose functionality is described below.
• Pause – Clicking the Pause button stops new events from
being displayed in the Log Information page. When clicked, the
icon changes to Resume. Click Resume to allow events to be
displayed again.
• Clear Log – Clicking the Clear Log button will clear the
records displayed in the Log Information page.
• Export Log – Clicking the Export Log button will allow you to
export and save the log file to your computer.
• Filter – Clicking the Filter button opens the Filter settings,
shown below, which allow you to display only records that
match the filter settings entered. The filter settings are
described in the table below.
